GIBSON COUNTY HIGHWAY SUPERINTENDENT: CHUCK LEWIS PH. 1-812-385-4887 1791 E. 350 S. PRINCETON, IN 47670 GIBSON COUNTY COMMISSIONERS MARY 8. KEY KEN MONTGOMERY WARREN FLEETWOOD COUNTY COMMISSIONERS OFFICE 225 N. HART STREET PRINCETON, IN 47670 PH: 812-385-8260 INDIANA DEPARTMENT OF TRANSPORTATION VINCENNES DISTRICT 3650 SOUTH U.S. 41 VINCENNES, IN 47591 PH: 1-800-279-5758 FAX: 1-812-895-7479 SHEET SCHEDULE • 1 COVER SHEET • 2 • 3 • 4-7 • 8-9 INFORMATION SHEET OVERALL SYSTEM MAP WATER MAIN PLAN SHEETS TYPICAL WATER DETAILS UTILITIES ELECTRICAL: VECTEN ENERGY 1 N. MAIN STREET P.O. BOX 209 EVANSVILLE, IN 47711 PH: 1-812-491-4765 ELECTRICAL: DUKE ENERGY 800 WHEATLAND RD. VINCENNES, IN 47591 PH: 1-812-886-3276 ELECTRICAL: WIN ENERGY REMC 3981 S. HWY 41 VINCENNES, IN 47591 PH: 1-812-882-5140 ELECTRICAL: INDIANAPOLIS POWER AND LIGHT 5858 N. COLLEGE AVE. INDIANAPOLIS, IN 46220 PH: 1-317-252-4007 ELECTRICAL: AEP (TRANSMISSION) 700 MORIS ROAD GAHANNA, OH 43230 PH: 1-614-552-1801 WATER: PIKE-GIBSON WATER, INC. 325 N. JACKSON STREET OAKLAND CITY, IN 47660 PH: 1-812-749-4916 ATTN: KEVIN STILWELL WATER: PATOKA LAKE REGIONAL WATER & SEWER DISTRICT 2647 NORTH S.R. 545 DUBOIS, IN 47527 PH: 1-812-687-2250 WATER: OAKLAND CITY 301 S. FRANKLIN STREET OAKLAND CITY, IN 47660 PH: 1-812-749-3222 WATER: PETERSBURG 704 E. MAIN STREET PETERSBURG, IN 47567 PH: 1-812-354-8511 GAS: OHIO VALLEY GAS 111 ENERGY PARK DR. WINCHESTER, IN 47394 PH: 1-765-584-6842 GAS: TEXAS GAS TRANSMISSION 3800 FREDERICA STREET OWENSBORO, KY 42301 PH: 1-270-688-6367 GAS: WIN ENERGY REMC 3981 U.S. HIGHWAY 41 VINCENNES, IN 47591 PH: 1-812-882-5140 TELEPHONE: AT&T 4517 E. INDIANA BELL CT. BLOOMINGTON, IN 47408 PH: 1-812-334-4718 TELEPHONE: FRONTIER 1233 W. TIPTON ST. SEYMOUR, IN 47274 PH: 1-812-525-1655 TELEPHONE: AVENUE BROADBAND 102 N. 5TH STREET VINCENNES, IN 47591 PH: 1-212-291-0594 HOLIY MOLIY SAYS, "CALL BEFORE YOU DIG" (TWO WORKING DAYS PLIASE) 1-800-382-5544 INSIDE IN� 1-800-428-5200 FROMOUTSIOE I� GENERAL NOTES: 1 . 2. 3. 4. 5. 6. 7. 8. 9. 10. TOPOGRAPHY SHOWN ON PLAN SHEETS IS INTENDED TO SHOW THE GENERAL LOCATION OF FENCES, CULVERTS, DRIVES, EXISTING UTILITIES, POINTS OF CONNECTION, ETC. HOWEVER; THE EXACT LOCATION AND QUANTITIES SHALL BE VERIFIED AT THE TIME OF CONSTRUCTION. THE HORIZONTAL LOCATION DATA IS BASED UPON THE INDIANA STATE PLANE COORDINATE SYSTEM (WEST ZONE) REFERENCED TO THE 1983 NORTH AMERICA DATUM (NAD83) ELEVATIONS ARE BASED UPON THE 1988 NORTH AMERICAN VERTICAL DATUM (NAVD 88) THE CONTRACTOR SHALL CALL INDIANA UNDERGROUND SERVICES AT 1-800-382-5544 PRIOR TO ANY CONSTRUCTION TWO FULL WORKING DAYS BEFORE CONSTRUCTION IS TO BEGIN. THE LOCATION OF EXISTING UTILITIES, ETC. SHOWN ON THESE PLANS ARE NOT THE EXACT LOCATIONS BUT ONLY A GENERAL LOCATION. ALTHOUGH THESE PLANS HAVE ATTEMPTED TO SHOW ALL EXISTING UTILITIES, THE CONTRACTOR SHALL NOT ASSUME ALL EXISTING UTILITIES HAVE BEEN SHOWN. THEREFORE IT SHALL BE THE CONTRACTORS RESPONSIBILITY TO SEE THAT ALL EXISTING UTILITIES WITHIN CONSTRUCTION AREAS ARE CLEARLY MARKED IN THE FIELD PRIOR TO ANY CONSTRUCTION IN THE AREA. EXACT LOCATION OF GATE VALVES, HYDRANTS, FITTINGS, ETC. TO BE DETERMINED AT THE TIME OF CONSTRUCTION. DOWN TIME COORDINATION MUST BE MADE WITH THE WATER UTILITY PRIOR TO WET OR DRY TAPPING WATER MAINS AND TAKING WATER STORAGE TANK(S) OUT OF SERVICE. COORDINATE WITH KEVIN STILWELL, UTILITY SUPERINTENDANT, AT 1-812-749-4916, A MINIMUM OF FIVE (5) WORKING DAYS PRIOR TO WET/DRY TAPPING OF MAINS OR TAKING A TANK OUT OF SERVICE. PROPERTY LINES, WHERE SHOWN, ARE BASED ON COUNTY PLAT RECORDS. THE SAID PROPERTY LINES ON THESE SHEETS DO NOT REPRESENT THE PROPERTY SURVEYS, BUT ARE ONLY APPROXIMATE LOCATIONS FOR REFERENCE PURPOSES ONLY. IF ANY ARCHAEOLOGICAL ARTIFACTS OR HUMAN REMAINS ARE UNCOVERED DURING CONSTRUCTION, THE CONTRACTOR SHALL STOP ALL EXCAVATION WORK AND CONTACT THE INDIANA DEPARTMENT OF NATURAL RESOURCES, DIVISION OF HISTORIC PRESERVATION AND ARCHEOLOGY AT 1-317-232-1646. NO ADDITIONAL EXCAVATION WORK SHALL BE DONE WITHOUT RECEIVING THEIR APPROVAL. THE CONTRACTOR SHALL BE REQUIRED TO IMPLEMENT DUST CONTROL MEASURE (SURFACE WETTING) AS NECESSARY TO MINIMIZE FUGITIVE DUST EMISSIONS. IF CAVERNS OR SPRINGS ARE ENCOUNTERED DURING EXCAVATION, WORK SHALL STOP IMMEDIATELY AND THE INDIANA DEPARTMENT OF NATURAL RESOURCES OR THE U.S. FISH & WILDLIFE OFFICE SHALL BE CONTACTED CONCERNING PROPER MITIGATION MEASURES. LEGEND 4" -•-•--'--•-•- t @ M t --�--- ---�--- ---�--- ___j:____ ___£___ 1M] EXISTING WATER MAIN AND SIZE EXISTING GATE VALVE EXISTING FLUSH HYDRANT EXISTING FIRE HYDRANT EXISTING BLOW-OFF VALVE EXISTING LEAK DETECTION DEVICE EXISTING PRESSURE REDUCING VALVE EXISTING SERVICE METER PROPOSED WATER MAIN AND SIZE PROPOSED GATE VALVE PROPOSED FLUSH HYDRANT PROPOSED FIRE HYDRANT PROPOSED BLOW-OFF VALVE SERVICE METER RELOCATION H.T. --HT-- TREE HOUSE HOUSE TRAILER BURIED TELEPHONE CABLE GAS MAIN HIGH TENSILE FENCE �x- WOVEN OR BARBED WIRE FENCE -w.1---�- WROUGHT IRON OR CHAIN LINK FENCE -c---/.- ELECTRIC OR WOOD FENCE ,? UTILITY POLE WITH GUY WIRE = = = = DRAINAGE CULVERT -,-------.- APPARENT PROPERTY LINE 26-06-06-30<HXX XXX-XXX - PARCEL NUMBER Doe, John & Jone -- PROPERTY OWNER OJ--- EASEMENT NUMBER �--- "X" DENOTES NO SIGNED EASEMENT. MAIN TO BE PLACED IN R / W OR AS NOTED ON PLANS PLAN SHEET INFORMATION • REVISIONS BID SET Cl 2023 Midwestern Engineers. Inc S02 West Brondwav Street P.O. Bo.x 295 • Loogootee. lndiuna 47553 DATE 2023 DESIGN R.D.W. DRAWN K.J.G. Q.C. CHECK PROJECT NUMBER 2020031-04 2 2 OF 9 I FllE NUMBER 53596 I Do Not Use Plan Previews for Take Off
