Midwestern Engineers, Inc. Plan Preview

< w r � w < w ' , " , < " 0 w 0 <> •' ,� ,� �� . ' mo Q ..... ,9 Nm �<ti 0 ,_ g� �� ,N �o ·" - .. • t; � " o, � "" • -, 0 "o 00 U wz z -, <� �(,J 5N §5<� METER BUILDING SCADA NOTES (PLRWSD) METER BUILDING SCADA NOTES (JASPER) 1. PROPOSED SCADA PANEL TO BE PROVIDED AND INSTALLED BY PLRWSD. SCADA CONTROL PANEL AT METER PIT SHALL INCLUDE THE FOLLOWING FEATURES: A. ZETRON MODEL 17 0 8 RTU B. LIGHTNING ARRESTOR C. RADIO D. OPTO ISOLATION FOR BOTH INPUTS AND OUTPUTS E. POWER SUPPLY F. POWER FAIL RELAY G. BATTERY BACK-UP WITH 7 AMP HR. BATTERY H. CIRCUIT BREAKER FOR INCOMING 1 2 0 V I. HAMMOND ENCLOSURE 36"x24"x8" NEMA 1 J. ACT PAK PER CIVIL DRAWINGS K. CONTROL VALVE HAND-OFF-AUTO SELECTOR SWITCH (ON WALL) 2. RTU INPUTS/OUTPUTS DIGITAL INPUTS: DIGITAL OUTPUTS: RTU POWER FAIL VALVE CLOSE (OVERRIDE) COMMUNICATION STATUS SITE POWER FAIL FLOOD ALARM CONTROL VALVE STATUS (OPEN/CLOSED) TOTALIZED FLOW PULSE INTRUSION ALARM ANALOG INPUT: INLET PRESSURE OUTLET PRESSURE INSTANTANEOUS FLOW RELAYS: FLOOD ALARM VALVE OPEN VALVE CLOSED VALVE IN AUTO 1 . CONTRACTOR SHALL UTILIZE CITY OF JASPER EXISTING SCADA SYSTEM INTEGRATOR. CONTACT NATHEN BURKHART WITH TORIC ENGINEERING AT 3 1 7-718- 1 80 0 TO PROVIDE SCADA CONTROL PANEL AT METER BUILDING WITH THE FOLLOWING FEATURES: A. ALLEN BRADLEY MICRO 850 PLC B. CELLULAR MODEM C. TVSS D. POWER SUPPLY E. POWER FAIL RELAY F. BATTERY BACK-UP G. THERMOSTATICALLY CONTROLLED HUMIDITY/CONDENSATION HEATER H. CIRCUIT BREAKER FOR INCOMING 1 2 0 V I. NEMA 1 ENCLOSURE J. PRECISION DIGITAL OISPLY FOR INLET PRESSURE, OUTLET PRESSURE AND FLOW K. ACT PAK PER CIVIL DRAWINGS L. KEYPAD TO SILENCE INTRUSION ALARM 2. RTU INPUTS/OUTPUTS DIGITAL INPUTS: DIGITAL OUTPUTS: RTU POWER FAIL VALVE OPEN SITE POWER FAIL VALVE OVERRIDE FROM PLRWSD CONTROL VALVE STATUS (OPEN/CLOSED) TOTALIZED FLOW PULSE FLOOD ALARM VALVE CONTROL IN AUTO INTRUSION ALARM ANALOG INPUT: INLET PRESSURE OUTLET PRESSURE INSTANTANEOUS FLOW (VIA PLRWSD ACT PAK) 3. PLRWSD SHALL COORDINATE, PROVIDE AND/OR INSTALL ALL EQUIPMENT, MATERIAL, WIRING PROGRAMMING AND SOFTWARE MODIFICATIONS TO THE MCU AT THE WATER TREATMENT PLANT TO ACCOMMODATE THE METER BUILDING 1/0 AS NEEDED FOR A FULLY FUNCTIONING SYSTEM. 3. CONTRACTOR SHALL COORDINATE w/ TORIC FOR PROGRAMMING AND SOFTWARE MODIFICATIONS TO THE MCU AT THE WATER TREATMENT PLANT TO ACCOMMODATE THE METER BUILDING 1/0 AS NEEDED FOR A FULLY FUNCTIONING SYSTEM. 4. COAX. ANTENNA AND MAST INSTALLED BY PLRWSD AT COMPLETION OF PROJECT. 4. TRANSDUCERS PROVIDED BY TORIC, CABLING, CONDUIT AND INSTALLATION BY PLRWSD. 5. TRANSDUCERS, FLOAT SWITCH, H-0-A SWITCH, CONDUIT, WIRING ANO TERMINATIONS BY PLRWSD. r -- 5. TORIC TO PROVIDE INTRUSION ALARM AND KEYPAD FOR ONSITE SILENCING, TO BE INSTALLED BY PLRWSD. r;==. l'L Pl. PL Pl Pl Pl �I PL pt_ pt ,r•-•-•-•-•-•-k-•-•-•-•7 Ii a GROfflDING ELECTRODE !-- --.:---, " SYSTEM, srn rLAN a™E�rn =�� / "' "' " '/ ti --- GENERAL ELECTRICAL NOTES 1 . ALL WORK SHALL COMPLY WITH INOIANA ELECTRICAL CODE, CURRENT EDITION. 2. ALL CONDUITS SHALL BE SCH. 8 0 PVC IF BURIED OR INSIDE METER BUILDING, ALUMINUM IF EXPOSED, FASTEN w/ STAINLESS HARDWARE. 3. ALL INDOOR ENCLOSURES SHALL BE NEMA 1 UNLESS OTHERWISE NOTED. 4. IN GENERAL THE BIDDING CONTRACTOR IS RESPONSIBLE FOR THE ELECTRIC SERVICE CONDUIT, WIRE AND METER BASE INSTALLATION. PLRWSD WILL DO GROUNDING, POWER, CONTROL, WIRING AND CONDUIT ASSOCIATED WITH THE PROJECT. THE BIDDING CONTRACTOR WILL BE RESPONSIBLE FOR PROVIDING AND INSTALLING JASPER'S SCADA PANEL MANUFACTURED BY TORIC ENGINEERING. TORIC WILL ALSO PROVIDE TWO TRANSDUCERS FOR JASPER PRESSURE READINGS TO BE INSTALLED BY PLRWSD. TERMINATIONS AND STARTUP OF JASPER'S SCAOA PANEL WILL BE BY TORIC ENGINEERING. 5. CONTRACTOR TO CONTACT GREG DILGER OF DUBOIS REC AT 8 1 2-482-5454 MIN. 3 WEEKS PRIOR TO COORDINATE ELECTRIC SERVICE INSTALLATION. ALL ELECTRIC UTILITY RELATED FEES TO BE PAID FOR BY OWNER. 6. SEPARATE POWER AND CONTROL CONDUITS, DIGITAL AND ANALOG. PANEL 100 AMPERES MCBMA!N CONNECTION MEIEB BilliDl�G LOCATION A CIRCUIT NO. 120/240 VOLTS "'iWIRE ITEM FEED ,..J__ SURGE ARRESTOR 3 5 LIGHTS 7 DEHUMIDIFIER 9 SUMP PUMP 11 SPARE 13 SPARE 15 SPARE Type A COLUMBIA LIGHTING - WIRE SIZE 8 12 12 12 12 12 12 1 PHASE "" KAIC AMPS POLE 50 2 20 1 20 1 20 1 20 1 20 1 20 1 cu. BUS A B A B A B A B POLE 1 1 1 2 1 1 1 SlJRFACE MOUNTING S.E.L WIRE ITEM FEED AMPS SIZE 20 12 RECEPTACLES 20 12 . ,.., ,.,.'" ..,..,.., f 20 12 SCADA PANEL (PLRWSO) 20 12 HEATER 20 12 SPARE 20 12 SPARE 20 12 SPARE LIGHT FIXTURE SCHEDULE Manufacturer / Model Mounting CATALOG No. LXEM4-4 0 VL-RFA-EDU-SSL, XEHC SURFACE B HUBBELL LIGHTING - CATALOG No. LNC-7LU-4K-3-2-BLT-PCU SURFACE CIRCUIT NO. 2 4 6 _L 10 12 14 16 Lamps 62W LED 16.4W LED I 'I 1, \ j rl9� "'\ !" #S CU. GND. IN 1 " CONDUIT EXOTHERMICALLY-· - -=-- --,- ----- -, WELDtD TO ¾"0x 1 0' CU. CLAD GND. ROD. ( TYP. OF 3 ON 1O' TRIANGULAR SPACING) CONTRACTOR TO PROVIDE AND INSTALL ONE 2)," SCH. 4 0 PVC CONDUIT w/ LONG SWEEP ELBOWS, PULL ROPE ANO 36" COVER FROM PROPOSED METER BASE LOCATION ON PROPOSED METER BUILDING TO BASE OF EXISTING TRANSFORMER POLE. DUBOIS REC WILL EXTEND CONDUIT RISER UP TRANSFORMER POLE THEN PULL IN CONDUCTORS TO METERING BUILDING. METER I ,/ I I" I ,/ I I" I ,! I II I �if I I! I I '! Id I NEW JASPER MASTER METER PIT BUILDING • " I \_ " " ; FIELD VERIFY EXACT LOCATION w/ ___.\ " ',. ✓ a OWNER DURING CONSTRUCTION f \ '- PRIOR TO INSTALLAflON ' \ d CONTRACTOR TO PROVIDE AND INSTALL ONE 2)," SCH.� \ 4 0 PVC CONDUIT WITH LONG SWEEP ELBOWS, PULL ROPE AND 36" COVER FROM PROPOSED METER BASE / LOCATION ON PROPOSED METER BUILDING TO BASE ,. OF EXISTING TRANSFORMER POLE. DUBOIS REC WILL \ ; 0 EXTEND CONDUIT RISER UP TRANSFORMER POLE THEN PULL IN CONDUCTORS TO METERING BUILDING. METER l BASE PROVIDED BY DUBOIS REC THEN INSTALLED BY CONTRACTOR, METERING BY DUBOIS REC. I </ -----t-- <' -- CL- Cl- Cl,- CL -- CC -- CC -- CC ---'\I <----- oo,----: EXISTING DUBOIS REC ----+- - +---+--- -___ 2 P :!: OL °': E ;;; TO REMAIN "= � OC = / t-1 ---- e,w , D l , I 0 PROPOSED ELECTRICAL SITE PLAN SCALE: 1 " � 10 ' COAX, ANTENNA AND MAST PROVIDED � AND INSTALLED BY PLRWSD SCADA PANEL PROVIDED AND INSTALLED BY PLRWSD /r FLOW, FLOOD ALARM, INTRUSION, CONTROL VALVE STATUS AUTO/OPEN/CLOSED ) ANO OVERRIDE NTERCONNECTIONS A-5 MOUNT @ 8'- 0 " AF.F. UNIT HEATER QMARK MUH 0 3-2 1 , 24 0 V-10, 3KW FLOAT SWITCH FOR FLOOD ALARM TO SCADA � / // /// / � ////, // / / c-.'v / A-2 � /; -� A-6 ,; V A-8, 10 :s:__� // JASPER SCADA PANEL PROVIDED AND :"-' / INSTALLED BY CONTRACTOR, CONDUIT � / AND WIRIG BY PLRWSD, /, 1---��--TERMINATIONS AND TESTING BY TORIC INLET PRESSURE A-4 TO PLRWSD RTU FLOW TO PLRWSD RTU BASE PROVIDED BY DUBOIS REC THEN INSTALLED BY CONTRACTOR, METERING BY DUBOIS REC. 2 00 A METER BASE PROVIDED BY DUBOIS REC, INSTALLED BY CONTRACTOR, METERING BY DUBOIS REC. II ', ,/' 11 , ; SURGE ARRESTOR FOR ELECTRIC SERVICE JOSLYN TPS SERIES MODEL TK-ST 1 2 0 - 1 S24 0 . MAKE LEADS AS SHORT AND STRAIGHT AS 1 �0SSIBLE. I t II A-2 PROPOSED 1 2 0 /24 0 V-10, 3W PANEL "A", SERVICE ENTRANCE RATED, NEMA 1 ENCLOSURE, SQ. D 1 ODA QO NO EQUAL A-5 CONTROL VALVE STATUS (OPEN/CLOSED) TO PLRWSD RTU II I II NOR LRWSD TO PROVIDE AND INSTALL CORROSION RESISTANT DOOR SWITCH AND CONTROL WIRE IN CONDUIT TO JASPER RTU FOR INTRUSION ALARM, SQ. D #9 00 7C54B2 OR EQUAL ROUTE DRAIN TO PIT // / // / / • / / ��� �� :,;-;,;,:,;;;:// /;:/ /,; FLOW METER, CONDUIT AND WIRING BY PLRWSD � H-0-A SWITCH, CONDUIT AND WIRING BY PLRWSD PROPOSED ELECTRICAL FLOOR PLAN SCALE: ½" � 1 '-0" ALTERNATE A- METER BUILDING ELECTRICAL PLAN REVISIONS 1/ 1 5/24 BID SET C) 2024 Midwestern E11girn:crs. Inc. 802 We$! Brnadw,1y S1re�I P.O. Box 295 Loogootee. Indiana47553 DATE JANUARY 2024 DESIGN A.F.B. DRAWN C.N.M. Q.C. CHECK R.D.W. PROJECT NUMBER 2021079-00 1 7 17 OF 17 FlLE NUMBER 43598 Do Not Use Plan Previews for Take Off
